AGT-KH18K-CC, with a 1-ton operating weight and 5.41-foot digging depth, is compact and reliable for maneuvering in tight spaces like farms, gardens, and parks, offering features like air conditioning, side swing, and an enclosed cab for a dust-free and comfortable work experience.

2024 Model

Technical Data:

• Operation Weight: 1 Ton
• Engine: Kubota Diesel Engine
• Equipped with Air Conditioned Enclosed Cabin
• Equipped with Side Swing

Engine:

• Brand: Kubota
• Model: D722
• Type: 3-cylinder diesel engine
• Power Output: 10.2 kW
• Maximum Speed: 3,600 RPM
• Emissions Compliance: Tier 4

Performance:

• Operating Weight: 980 kg (2,160 lbs)
• Maximum Digging Depth: 1,693 mm (66.7 inches)
• Maximum Digging Height: 2,560 mm (100.8 inches)
• Maximum Loading Height: 1,800 mm (70.9 inches)
• Minimum Rotation Radius: 3,060 mm (120.5 inches)
• Travel Speed: 0-1.8 km/h
• Climbing Ability: 15°

Dimensions:

• Overall Length: 2,925 mm (115.2 inches)
• Overall Width: 958 mm (37.7 inches)
• Overall Height: 2,422 mm (95.4 inches)

Hydraulic System:

• Main Pump Type: GP510803
• Rated Set Pressure: 25 MPa
• Maximum Flow Rate: 21.6 L/min
• Multi-Circuit Valve: 4 mechanical + 4 hydraulic
• Rotary Hydraulic Motor Type: BM2-315
• Traveling Hydraulic Motor Type: BM6-315

Additional Features:

• Cabin: Enclosed with air conditioning
• Side Swing: 30° angle
• Bucket Capacity: 0.03 m³
